am-zerspanungstechnik  |  SKU: 140922_0062

Short tap, fine thread, through-cut tap, right

$6.00


Guarantee & Quality

We guarantee our customers the highest quality and longevity.

Shipment

Depending on the customer location, shipping takes place after 1-2 business days .
Orders over €130 receive tracking.

Description

Stock number: 1168 - 1185 Application for industrial taps for short AM machining technology

Fine tap short M2x0.4 - M36x4

Single-cut tap with tolerance 6H.

The tap is suitable as a machine tap and also as a hand tap.

Metric thread with a flank angle of 60°.

From M8 onwards, the shaft diameter is small enough to cut deeper threads.

A maximum depth of 2.5xD is possible up to M8.

Cutting data Vc m/min:

Cutting data tap short AM machining technology single-cut tap

MF tap

Cutting Ø Dc

Total length L

Shank Ø Ds

Cutting Ø Dc

Total length L

Shank Ø Ds

M2 – M2.3

36mm

Ø 2.8mm

M30 x 1.5 /2

90mm

Ø 22mm

M2.5 – M2.6

40mm

Ø 2.8mm

M30x3.5

125mm

Ø 22mm

M3

40mm

Ø 3.5mm

M33 x 1.5 /2

100mm

Ø 25mm

M3.5

45mm

Ø 4mm

M33x3.5

125mm

Ø 25mm

M4

45mm

Ø4.5mm

M35x1.5

100mm

Ø28mm

M5 – M7

50mm

Ø 6mm

M36 x 1.5 /2

125mm

Ø28mm

M8

56mm

Ø 6mm

M36x4

148mm

Ø28mm

M9 – M10x1.25

63mm

Ø 7mm

M10x1.5

70mm

Ø 7mm

M12x1/1.5

70mm

Ø 9mm

M12x1.75

75mm

Ø 9mm

M13 x 1/1.5

70mm

Ø 11mm

M14 x 0.75/1.5

70mm

Ø 11mm

M14x2

80mm

Ø 11mm

M16 x 1/1.5

70mm

Ø 12mm

M16x2

80mm

Ø 12mm

M18 x 1/2

80mm

Ø 14mm

M18x2.5

95mm

Ø14mm

M20 x 1/2

80mm

Ø16mm

M20x2.5

95mm

Ø16mm

M22 x 1/2

80mm

Ø 18mm

M22x2.5

100mm

Ø 18mm

M24 x 1/2

90mm

Ø 18mm

M24x3

110mm

Ø 18mm

M26x1.5

90mm

Ø 18mm

M27 x 1.5 /2

90mm

Ø 20mm

M27x3

110mm

Ø 20mm

M28x1.5

90mm

Ø 20mm
